HIGH FLOW AIR/O2 BLENDER

The 120L Low Flow Oxygen Blender mixes medical grade compressed air and oxygen to provide a pressurized gas source ranging from 21 to 100  percent oxygen.

• 24 month warranty
• Compact size
• Low maintenance

Please allow up to 1 week lead time depending on quantity and configuration ordered.

Manufactured and assembled in the USA.

Specifications

• Size: 3.5”H (9cm) x 2.25”W (5.6cm) x 4.5”D (11.5cm)
• Model Weight: 2.75 lbs (1.4 kg)
• Gas Supply Pressure: 30-75 PSIG (2.11 kg/cm2 – 5.27 kg/cm2)
• Knob Adjustment Range: 21% – 100%
• Primary Outlet Flow Range: 15 to 120 LPM (no bleed)
• Maximum Flow @ 60% Knob Setting: 120 LPM
• Flow @ 21% of 100% Knob Setting: 90 LPM
• Auxiliary Outlet Flow Range: 2 to 100 LPM (bleed 10-12 LPM)
• Accuracy: ±3% of full scale over the stated flow ranges
• Alarm/Bypass Activation: When inlet gas pressures differ by 20 PSI ±2 or more
• Alarm Sound Generator: Vibrating reed
• Alarm/Bypass Reset: When inlet pressure differential is 6 PSIG or less
• Pressure Drop: Less than 6 PSIG at 50 PSIG inlet pressure and 40 LPM
